HAAS ST-30Y 2019
3 Jaw Chuck , C axis & Milling , Coolant , Interlocked guards , Low Volt Light , Swarf Conveyor , Tailstock , Tool setter , Y-axis
HAAS ST-30Y 2019
Key Features
Type:
All Products
Model:
ST-30Y
Make:
HAAS
Year:
2019
Serial No
3116613
Price
£POA
Our Reference
Location
Leicester
HAAS ST-30Y 2019
Specifications
Bar Capacity
76mm
C axis
0.01 degree
Chuck Size
254mm
Control
HAAS
Distance Between Centres
762mm
Machine Dimensions
4521 x 2515 x 2108mm
Machine Weight
5988kg
Maximum Cutting Diameter
457mm
Maximum Cutting Length
584mm
Milling RPM
6000rpm
Rapid Feedrates
XYZ: 12 x 12 x 24m/minute
Spindle Motor Power
22.4kW
Spindle Nose
A2-6
Spindle Speed
3400rpm
Swing
806mm
Swing over the Cross-slide
527mm
Tailstock Taper
MT #4
Tooling Configuration
VDI40/BOT Hybrid
Turret Positions
12 Station
X axis Travel
318mm
Y axis Travel
+/- 50.8mm
Z axis Travel
584mm
