DMG MORI NLX3000 2018

3 Jaw Chuck , C axis & Milling , Coolant , Interlocked guards , Low Volt Light , Parts Catcher , Swarf Conveyor , Tailstock , Tool setter , Y-axis
Key Features Gallery Specifications More in Stock Register Interest
DMG MORI NLX3000 2018

Key Features

Type:

All Products

Model:

NLX3000

Make:

DMG MORI

Year:

2018

Serial No

7514NL3031801071

Price

£POA

Our Reference

PM9774

Location

Leicester

DMG MORI NLX3000 2018

Specifications

Bar Capacity

90mm

C axis

0.001 degree

Chuck Size

12" (300mm)

Control

CELOS WITH MAPPS V

Distance Between Centres

1250mm

Machine Dimensions

5478 x 2480 x 2362mm

Machine Weight

8900kg

Maximum Cutting Diameter

430mm

Maximum Cutting Length

1260mm

Milling RPM

10000rpm

Spindle Motor Power

22/18.5kW

Spindle Nose

A2-8

Spindle Speed

3000rpm

Swing

978mm

Swing over the Cross-slide

808mm

Tool Size

25 x 25mm

Turret Positions

12 Station

X axis Travel

280mm

Y axis Travel

+/-60mm

Z axis Travel

1370mm
