5 Axis Machining Centres

Mazak VARIAXIS i600 2016

5 Axis Simultaneous , Coolant , Interlocked guards , Low Volt Light , Swarf Conveyor , Through Spindle Coolant

Key Features Gallery Specifications More in Stock Register Interest

Mazak VARIAXIS i600 2016

Key Features

Type:

5 Axis Machining Centres

Model:

VARIAXIS i600

Make:

Mazak

Year:

2016

Serial No

278313

Price

£POA

Our Reference

Location

Leicester

Mazak VARIAXIS i600 2016

Specifications

C axis

360 degrees

Control

MAZATROL SMOOTH

Machine Dimensions

2200 x 4885 x 3187mm

Machine Weight

13000kg

Maximum Tool Diameter

90mm

Maximum Tool Diameter with Empty Adjacent Pockets

130mm

Maximum Tool Length

300mm

Maximum Tool Weight

8kg

Maximum Workpiece Size

700 × 450mm

Maximum workpiece weight

500kg

Min - Max Height under Spindle

70 ~ 580mm

Number of Axis Controlled

5 Simultaneous

Rapid Feedrates

XYZ: 60 x 60 x 56m/minute

Rapid Feedrates

A & C: 50rpm

Spindle Motor Power

22/15kW

Spindle Speed

12000rpm

Table Size

600 × 500mm

Tool Change Capacity

30 Station

Tool Change Time (Chip to Chip)

3.4 seconds

Tool Size

ISO40

Mazak VARIAXIS i600 2016
